Innovative aluminium profile
Profile that is identical all the way around for flexible positioning within the stage construction,
more flexibility and a significant reduction in the amount of materials required when working with uneven dimensions.
Bevelled profile for maximum comfort during handling and assembly.
The bevelled profile is ideal for connecting ramps.
Universal plug-in leg mount
The unique leg mount from 2M enables the use off all conventional plug-in leg systems using round tubing with a diameter of 48.3 mm and square tubing with a diameter of 55 x 55 mm or 60 x 60 mm. The legs can be compacted using either an eccentric quick release system or using adjustment screws, depending on your requirements.
Robust plastic corner
Unlimited use in scaffolding constructions.
Robust design made of glass fibre-reinforced plastic with multifunctional guide.
Simple connection of clamp connectors and accessories thanks to the open groove channel.
Available as phenolic plywood (birch throughout) or Hexa plywood – both of which are resistant to the effects of weathering.
Countersunk screws for an even surface with a high-quality appearance.
The surface is connected via screws, which makes it easy to replace in the event of a repair.
The frame profile, which is the same all the way around, allows you to install the stage platforms in any direction within an event construction. Thanks to the ergonomic, bevelled profile, assembling the stage platforms is simple and comfortable.
Inner groove channel is used to mount the integrated platform retainer.
Outer groove channel enables compatibility with a wide range of other platform systems.
Platform corner including plastic corner
Platform corner without plastic corner
2 m x 1 m, 2.07 m x 1.04 m, 2.07 m x 0.86 m
Special size possible
Backing plate thickness
Horizontal test load
1/10 of the vertical test load
Vertical test load
8.5 kN/m2 (867 kg/m2)
Horizontal traffic load
1/10 of the vertical traffic load
Vertical traffic load
5.0 kN/m2 (510 kg/m2)
Max. stage height
DIN 13814, 4112, 1055, 15921
Are you interested in our platforms? Send us a brief enquiry and you’ll receive a perfectly tailored selection of products directly from 2M.
Every 2M stage platform from the ERGO series is manufactured in our certified production facility in Ratingen and tested by the TÜV in accordance with the latest standards and directives.
